Guideline 3


Born from users' experience, Guideline works in combination with FCS System to define the clamping in a early stage, with significant savings of work capacity.

MAIN FEATURES

  • Model import from CAD (via STEP)
  • Full FCS components library, customizable
  • Definition of FCS placement seats
  • Semi-automated FCS components placement
  • Multi-clamping definition per piece
  • Stock creation and placement
  • Multi-machines clamping
  • Model export to CAD (via STEP)
  • Bill of material generation and management
  • Automated documentation and instruction generation

ADDITIONAL COMPONENT

NX Package

  • Integrated geometry exchange with Siemens NX
  • Import model from Siemens NX with correct orientation
  • Export placement seats geometry in Siemens NX
  • Automatically creates seats in Siemens NX


Download latest release 3.262

Download documentation


Request a trial license
